Specifications |
| MODEL |
CPN102 |
CPN101 |
Video input
[ CCD sensor ] |
1 Channel |
2 Channel |
| Audio Input |
1 Channel |
_ |
Alarm Input
|
2 inputs / 1
output |
4 inputs / 2
output |
| Watch dog |
 |
|
| RS-485 Port |
|
|
Network Interface
[Ethernet(10/100 Base-T)] |
|
|
| Image Compression |
MPEG-4/JPEG |
JPEG |
| Video Adjustment |
Brightness,
Contrast, Saturation, Hue
|
Brightness,
Contrast, Saturation, Hue |
Protocols
|
TCP/IP,
ICMP, SMTP, FTP, HTTP,
DHCP, DDNS, PPPOE, NTP
|
TCP/IP,
ICMP, SMTP, FTP, HTTP |
| Resolution |
704
x 480, 352 x 240 <NTSC>
704 x 576, 352 x 288<PAL>
|
704x480,
352x240 <NTSC>
704x576, 352x288 <PAL> |
| Performance |
UP
to 24<NTSC>, 20<PAL> frames/second
|
UP
to15<NTSC>, 12.5<PAL> frames/second |
Motion Trigger Recording
|
|
_ |
| Motion Detection |
|
_ |
Triger & Action
|
Triggered
by GPIO Input, Action: E-mail video/imagesor video/images
upload to FTP site's specific accounts |
| Instaiiation |
Assign
static/dynamic IP address,additional router is not necessary |
Security
[Password protection]] |
|
|
Power Source [DC12V]
|
|
|
Current Consumption [500mA]
|
|
|
= Yes,
= N/A. |
|
|
