Characteristic

Backlight compensation: Auto
IP Rate: 68 water resistance
Electronic Shutter: Auto
Beautifully designated configuration
540 TVL 1/3 SONY SUPER HAD CCD
Illumination 0.01 lux
Adopts "special lens" no focus shift, the focal day and night clear
Patented "Heat-Radiation"

@
@ @ @
@
Features
ITEMS Description
Picture Elements HxV NTSC/EIA:510*492;PAL/CCIR:500*582(medium)
Picture Elements HxV NTSC/EIA:768*494;PAL/CCIR:753*582(High)
H.Sync Frequency NTSC:15.734 KHz, PAL:15.625KHz
V. Sync Frequency NTSC:59.94 Hz, PAL:50 Hz
Lens(mm) 3.6/6/8/12 mm
Night Vision No limited under 0.01 Lux
Electronic Shutter Auto, Rang: 1/50 (1/60)~ 1/100,000 sec.
S/N Ratio More than 48dB (AGC off)
Video Output 1 Vp-p, 75 Ohms
Power Supply Power Supply DC 12V (+/- 10%))
Chips 1/3" SONY 11X
Resolution 540 TV Line
@
@ @ @
@
@Designs and specifications are subject to change without notice.
@
@ @ @
