Evolution for your
Demand |
|
 |
Characteristics |
| This mini dome camera series can be easily installed in any applications
for users to monitor a wide range of area. |
| Features |
| |
CPC622 |
CPC329 |
| 1/3" Sony Color Super HAD CCD sensor |
|
 |
| 1/3" HR Color CCD sensor |
|
|
| Min.Illumination 1Lux / F2.0 |
|
|
| Min.Illumination 0.5Lux / F2.0 |
|
|
| S/N ratio more than 48dB (AGC off) |
|
|
| Audio function |
|
|
|
| |
|
Specifications |
| MODEL |
CPC622 |
CPC329 |
Pick-up Element
|
1/3" HR Color CCD sensor |
1/3" SONY Color Super HAD CCD |
Number of Pixel
|
771(H) x 492(V) <N>
753(H) x 582(V) <P> |
512(H) x 492(V)<N>
512(H) x 582(V)<P> |
| Resolution |
H.R. |
Standard |
| Min.Illumination |
1 Lux / F2.0 |
0.5 Lux / F2.0 |
S/N Ratio
|
More than 48dB |
| Electronic Shutter |
1/60(1/50) to 1/100,000 sec. |
| Lens |
f3.6mm/ F2.0 |
| Iris Mode |
AES |
| BLC |
N / A |
On |
| AGC |
N / A |
Max |
| White Balance |
ATW |
| Color Rolling Suppress |
N / A |
On |
| Video Output |
1.0 Vp-p composite, 75Ω |
| Microphone |
N / A |
Yes |
| Power Source (± 10%) |
DC12V |
| Current Consumption (± 10%) |
90mA |
105mA |
| Operating Temperature |
0℃ ~40 ℃(32℉ ~104℉) |
| Dimension (mm) |
104 (Φ) × 60 (H) |
| Net Weight (g) |
210 |
|
|
| * Designs and specifications are subject to change without notice. |
|
 |
